Lexus ES (XZ10) Service Manual / Vehicle Exterior / Door / Hatch / Luggage Compartment Door Opener Main Switch / Components

COMPONENTS

ILLUSTRATION

*1

GLOVE COMPARTMENT DOOR ASSEMBLY

*2

LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
